What are the technical features of the refrigeration copper tube airtightness water test machine

　　

水检机通过水循环系统来对铜管进行检测，是用于直条高效管气密及泡水检测的专用设备，以确保系统的正常运行和高效性能。那制冷机铜管气密性水检机有哪些技术特点，来看广州智品汇电子科技是如何介绍的。
The water leak detector uses a water circulation system to test copper tubes. It's specialized equipment for testing straight, high-efficiency tubes for airtightness and water immersion, ensuring proper system operation and high performance. What are the technical features of this refrigeration copper tube airtightness detector? Let's see how Guangzhou Zhipinhui Electronic Technology describes it.

1. Equipment Power: AC220V/50Hz/0.5kW.

2. Low-Pressure Air Source: ≤0.8MPa clean compressed air.

3. Medium-Pressure Air Source: ≥4.0MPa clean compressed air.

4. Station Cycle Time: 1 out, 5 out (10 units/minute, pressure holding period calculated as 15 seconds).

5. Air Test Pressure: Adjustable from 0.05 to 4.0MPa, 1.6-level pressure gauge, 5 independent channels.

6. Applicable Tube Specifications: 5 sizes: Φ15.88, Φ19.05, Φ22.23, Φ25.4, and Φ28.57, with 10 sealing heads provided for each size.

7. Applicable Tube Length: 1000-7000mm.

8. Adjustable Pressure Holding Time: 0-999s
