How to test the destructive test device of air conditioner capacitor

This series of devices is based on the latest standards such as GB 3667.1-2016, GB 18489, VDE0560-8, IEC60252, etc. How does the air-conditioning capacitor destructive test device perform tests? Let’s see how Guangzhou Zhipinhui Electronic Technology introduces it.
　

　　Destructive test items are carried out on AC motor running capacitors and AC motor self-healing starting capacitors with rated voltage of 500V and below. Contains two parts: DC test instrument and AC instrument. The DC power supply should be able to provide an open circuit voltage equivalent to 10UN and have the ability to provide a continuous short-circuit current greater than 50mA; the AC power supply should be able to provide a test voltage equivalent to 1.3UN, and the instantaneous short-circuit current should be at least 300A. The equipment has DC voltage and current, AC voltage and current display; the equipment also has load short circuit, overload and other protection measures; it has the characteristics of simple operation, intuitive display, and convenient adjustment.

Provide P1, P2 or S1/S2, S3 safety standard compatibility test.

The whole machine adopts PLC+touch screen control, automatically controls the boost and buck, and automatically completes the test.
