400-816-6687ZH-TPH23-3AQF/W Handheld Thermal Imaging Thermometer n Fixed-focus thermal imaging lens, 3.6 mm n Minimum focusing distance: 0.5 m n Resolution: 256 × 192 high-sensitivity detector n 3.5-inch touchscreen that can be used in sunlight n Supports maximum temperature, minimum temperature, and center positioning n Supports point, line, and box temperature measurement n Temperature measurement range: -20 °C~150 °C or 100 °C~550 °C n Temperature measurement accuracy: ±2 °C or ±2% of the reading (whichever is greater) n Supports 3D noise reduction function, digital zoom, false color adjustment, and contrast adjustment n Supports the fusion of thermal imaging and visible light n In conjunction with the app, it supports remote album access, download, and rapid report generation n Supports Weiying Thermal Vision APP, Analyzer, and UVC screen projection software Specification Parameters Sensor type: Uncooled detector Response band: 8~14 μm NETD (Noise Equivalent Temperature Difference): < 50 mk (@25 °C, F#=1.0) Maximum image size: 256 × 192 Focal length of thermal imaging lens: 3.6 mm Minimum imaging distance: 0.5 m ·Thermal Imaging Field of view: 50° × 37.2° Digital zoom: 1.0~8.0 continuous digital zoom Frame rate: 25 Hz F-number: F1.0 Minimum measurement distance: 0.5 m Temperature measurement range: -20 °C~550 °C Accuracy: ±2 °C or ±2%, whichever is greater Spatial resolution (IFOV): 3.33 mrad Focus mode: Fixed focus, non-adjustable Maximum image size: 3264 × 2448 (8 MP) ·Visible Light Picture resolution: 3264 × 2448 Video resolution: 1600 × 1200 Display: 3.5'' LCD capacitive touchscreen, 640 × 480 ·Image Display Image mode: Supports 7 false color modes including white hot, black hot, rainbow, iron red, red hot, fusion, and rain. It also supports two-stage false color functions such as high-temperature focusing. Picture display mode: Visible light, thermal imaging, dual-light fusion, picture-in-picture Bluetooth: Supported Laser indication: Supported Photography: Thermal imaging, visible light, dual-light fusion, picture-in-picture Video recording: Thermal imaging, visible light, dual-light fusion, picture-in-picture Lighting: Supported Text annotation: Supported ·System Functions Voice annotation: Supported (60 s) Interface language: Chinese WIFI: Supported Storage: 16 G (maximum support 128 G) Hardware interface: TYPE-C Battery type: Lithium-ion battery Battery working time: 6h, can be replaced on-site, rechargeable Operating temperature and humidity: -10 °C~50 °C, ≤95% ·System Parameters Protection level: IP54 Drop resistance level: 2 m Weight: 660 g Dimensions: 244 mm × 100 mm × 104 mm Accessories: Batteries (2), lanyard, charger, SD card, USB cable, desktop charger adapter, high-strength impact-resistant portable case
ZH-TPH23-3AQF/W Handheld Thermal Imaging Thermometer n Fixed-focus thermal imaging lens, 3.6 mm n Minimum focusing distance: 0.5 m n Resolution: 256 × 192 high-sensitivity detector n 3.5-inch touchscreen that can be used in sunlight n Supports maximum temperature, minimum temperature, and center positioning n Supports point, line, and box temperature measurement n Temperature measurement range: -20 °C~150 °C or 100 °C~550 °C n Temperature measurement accuracy: ±2 °C or ±2% of the reading (whichever is greater) n Supports 3D noise reduction function, digital zoom, false color adjustment, and contrast adjustment n Supports the fusion of thermal imaging and visible light n In conjunction with the app, it supports remote album access, download, and rapid report generation n Supports Weiying Thermal Vision APP, Analyzer, and UVC screen projection software Specification Parameters Sensor type: Uncooled detector Response band: 8~14 μm NETD (Noise Equivalent Temperature Difference): < 50 mk (@25 °C, F#=1.0) Maximum image size: 256 × 192 Focal length of thermal imaging lens: 3.6 mm Minimum imaging distance: 0.5 m ·Thermal Imaging Field of view: 50° × 37.2° Digital zoom: 1.0~8.0 continuous digital zoom Frame rate: 25 Hz F-number: F1.0 Minimum measurement distance: 0.5 m Temperature measurement range: -20 °C~550 °C Accuracy: ±2 °C or ±2%, whichever is greater Spatial resolution (IFOV): 3.33 mrad Focus mode: Fixed focus, non-adjustable Maximum image size: 3264 × 2448 (8 MP) ·Visible Light Picture resolution: 3264 × 2448 Video resolution: 1600 × 1200 Display: 3.5'' LCD capacitive touchscreen, 640 × 480 ·Image Display Image mode: Supports 7 false color modes including white hot, black hot, rainbow, iron red, red hot, fusion, and rain. It also supports two-stage false color functions such as high-temperature focusing. Picture display mode: Visible light, thermal imaging, dual-light fusion, picture-in-picture Bluetooth: Supported Laser indication: Supported Photography: Thermal imaging, visible light, dual-light fusion, picture-in-picture Video recording: Thermal imaging, visible light, dual-light fusion, picture-in-picture Lighting: Supported Text annotation: Supported ·System Functions Voice annotation: Supported (60 s) Interface language: Chinese WIFI: Supported Storage: 16 G (maximum support 128 G) Hardware interface: TYPE-C Battery type: Lithium-ion battery Battery working time: 6h, can be replaced on-site, rechargeable Operating temperature and humidity: -10 °C~50 °C, ≤95% ·System Parameters Protection level: IP54 Drop resistance level: 2 m Weight: 660 g Dimensions: 244 mm × 100 mm × 104 mm Accessories: Batteries (2), lanyard, charger, SD card, USB cable, desktop charger adapter, high-strength impact-resistant portable case
Zhipinhui after-sales service
Equipment after-sales policy:
*Equipment warranty period: One Year
*After sales hotline: 4008166687
1. Our company has assembled a team of experienced on-site engineers and senior technicians who can respond promptly to any equipment issues and provide after-sales maintenance.
2. Within one week of the delivery of the new product, our after-sales technical department staff will provide installation and after-sales training for the equipment at the customer's location based on the contact information and address provided by the customer.
3. All complaints related to product quality will be responded to within 1 hour. Within 3-5 hours within the province and 24-48 hours outside the province, the customer will arrive at the scene and determine the handling measures based on the complaint situation, and carry out after-sales maintenance.
4. To better address customers' difficulties and concerns, our company promises that all maintenance personnel will be on call.
5. Any costs related to product quality during the shelf life will be borne by our company.
6. During the warranty period, we will provide free repairs due to improper use by your side or natural environment. The materials and accessories used for repairs will only be charged at cost price.
