HR-150A manual Rockwell hardness tester

Non-standard products
Delivery
Free delivery
400-816-6687

HR-150A manual Rockwell hardness tester is a popular Rockwell hardness tester with mechanical manual testing and no electrical device. It has good economy and practicality, wide application range and easy operation.

Scope of application
Quenched steel, quenched and tempered, annealed steel, chilled castings, forgeable castings, aluminum alloys, copper, bearing steel, etc.


技术数据(Technical Specifications)

洛氏标尺(Rockwell Scales)

HRA,   HRB, HRC, HRD, HRE, HRF,HRG,HRH,HRK

初试验力(Initial Testing Force)

10Kg(98.07N)

试验力(All Testing Force)

60Kg   (588N), 100Kg (980N), 150Kg (1471N)

硬度读取

(Indication   of Hardness Value)

表盘式(Dial )

试件最大高度

Max.   Height of Specimen

170mm

仪器尺寸(Overall Dimension)

520X240X700MM   (长X宽X高, LXWXH)



仪器重量(Net Weight)

80   Kg

执行标准 (Carried Standard)

GB/T230.2   国家标准、JJG112检定规程

GB/T230.2   Chinese Standard and JJG112 Inspection Rule

标准配件、附件

(Standard   Accessories)

金刚石洛氏压头,直径1.5875mm硬质合金球压头,大平试台、中平试台、V型试台,硬度块

Diamond   Rockwell Indenter, Diameter 1.5875mm Hard Alloy Steel Ball Indenter, Large   Testing Table , Medium Testing Table and V-shaped Testing Table, HRC and HRB   Hardness Blocks
