ET3260A six and a half digit multimeter-Product Introduction

Basic Features:

² 6 1/2-bit resolution;

² The display uses a 3.5-inch color screen (resolution 320*480), which has rich display content and can flexibly display various graphical interfaces with good display effects; the display interface can be customized according to your needs, and optional graphics, numbers, mathematics and other functions can be displayed on the interface at the same time;

² Dual parameter display, which can display two parameters of the same input signal (for example, the AC voltage value and AC frequency value can be displayed simultaneously under AC voltage measurement);

² Remote operation through IEEE 488 (GPIB) interface, RS-232 interface, LAN interface, and USB Device interface;

² ET3260 has a GPIB communication interface, and ET3260A does not have a GPIB interface;

² It has trigger input and measurement completion output functions;

² The front panel has a USB port for data storage, program upgrade and configuration;

² Resistance two-wire and four-wire measurement, 10Ω and 1GΩ extended range;

² Period and frequency measurement, frequency up to 300KHz;

² Capacitance measurement;

² Temperature measurement, users can set their own sensor measurement;

² Maximum current measurement capability up to 12A;

² Multiple mathematical functions: statistics (maximum, minimum, average), zero elimination, dB, dBm, limit;

² Graphic display: trend chart, histogram, historical curve, list and other display modes;

² Support SCPI programming language and multiple command sets;

² Input terminals are provided on the front and back panels of the instrument;

² With internal and external calibration functions;
