ZH8862 Hydraulic Blasting Machine

I. Equipment Overview

This water pressure testing bench is a set of testing equipment independently developed by our company based

on the requirements of domestic and foreign customers and in accordance with relevant national and industry

standards. It utilizes imported components and a programmable controller. It can be used for burst and pressure

resistance tests on various pressure-bearing components of household appliances. The test bench can be set within a

60MPa range via a control panel or regulator. When a workpiece is damaged, the test bench automatically records the

actual water pressure of the damage and automatically shuts down the booster pump and other electrical devices,

thus shutting down the entire system. It features both automatic and manual boosting functions, is easy to operate,

safe, reliable, aesthetically pleasing, and convenient.

II. Main Performance Parameters:

1. Power Supply: 220VAC 50Hz 2KW Single Phase

2. Operating Ambient Temperature: 25℃±15℃ Relative Humidity: 45%~95% RH

3. Pressure Range: 0.8～60MPa

4. Medium Temperature: Room Temperature

5. High-Pressure Water Pump: Gas-Liquid Booster Pump, Maximum Pressure 60MPa

6. Test Sample Volume: Below 10L

7. Working Medium: Clean Water

8. High-Pressure Venting Function

9. Automatically Adjustable Pressure Rise and Fall Frequency: Range 50~500KPa/second, servo automatic control

during pressure rise and fall

10. Test Chamber: Dimensions manufactured according to various components on an air conditioner

III. Test Functions:

1. Static Pressure Test

6.3MPa water pressure holding for 3min

13MPa holding for 3min

21MPa holding for 3min

Other conditions: Static pressure test 0.5~60MPa

Automatic pressure release after test completion.

2. Burst Test: Destructive test, pressure 0.5~60MPa, record the highest pressure after sample rupture.
