400-816-6687Air conditioning thermal balance test room
1. Overview
This test room uses the heat balance method to test the cooling capacity, heating capacity, power consumption and C.O.P. of room air conditioners. Its test state is close to the actual working state of room air conditioners, and its indoor measurement results can be verified by the outdoor measurement results, so it is usually used as a benchmark test room for measuring room air conditioner capacity. The test room conditions meet the requirements of standards GB/T 7725-2004 and JIS B 8615-1.
The measurement principle of this test room is to measure the heat and water input (or extracted) by the test device to balance the cooling capacity and dehumidification capacity of the tested air conditioner during cooling or the heating capacity during heating, so as to determine the performance of the air conditioner; the test results are based on the results measured indoors, and the outdoor side is used as an auxiliary measurement for verification. The difference between the results measured outdoor and indoor should be within ±4%.
二. Test items
1. Rated cooling capacity test
2. Rated heating capacity test
3. Intermediate cooling capacity test
4. Intermediate heating capacity test
III. Technical specifications (the following specifications are for reference only and can also be customized according to user requirements)
1. Typical test conditions:
Rated cooling capacity: Indoor air state - dry bulb temperature 27℃, wet bulb temperature 19℃
Outdoor air state - dry bulb temperature 35℃, wet bulb temperature 24℃
Rated heating capacity: Indoor air state - dry bulb temperature 20℃, wet bulb temperature <15℃
Outdoor air state - dry bulb temperature 7℃, wet bulb temperature 6℃
2. Cooling capacity test range: 1.5 ~ 8 kW
3. Heating capacity test range: 1.5 ~ 9 kW
4. Dry bulb temperature control accuracy: ±0.1℃
5. Wet bulb temperature control accuracy: ±0.1℃
6. Repeatability accuracy: ±1%
7. Accuracy: ±2%
8. Indoor and outdoor thermal balance ratio: ±2%
Air conditioning thermal balance test room
1. Overview
This
test room uses the heat balance method to test the cooling capacity,
heating capacity, power consumption and C.O.P. of room air conditioners.
Its test state is close to the actual working state of room air
conditioners, and its indoor measurement results can be verified by the
outdoor measurement results, so it is usually used as a benchmark test
room for measuring room air conditioner capacity. The test room
conditions meet the requirements of standards GB/T 7725-2004 and JIS B
8615-1.
The measurement principle of this test room is to measure
the heat and water input (or extracted) by the test device to balance
the cooling capacity and dehumidification capacity of the tested air
conditioner during cooling or the heating capacity during heating, so as
to determine the performance of the air conditioner; the test results
are based on the results measured indoors, and the outdoor side is used
as an auxiliary measurement for verification. The difference between the
results measured outdoor and indoor should be within ±4%.
二. Test items
1. Rated cooling capacity test
2. Rated heating capacity test
3. Intermediate cooling capacity test
4. Intermediate heating capacity test
III.
Technical specifications (the following specifications are for
reference only and can also be customized according to user
requirements)
1. Typical test conditions:
Rated cooling capacity: Indoor air state - dry bulb temperature 27℃, wet bulb temperature 19℃
Outdoor air state - dry bulb temperature 35℃, wet bulb temperature 24℃
Rated heating capacity: Indoor air state - dry bulb temperature 20℃, wet bulb temperature <15℃
Outdoor air state - dry bulb temperature 7℃, wet bulb temperature 6℃
2. Cooling capacity test range: 1.5 ~ 8 kW
3. Heating capacity test range: 1.5 ~ 9 kW
4. Dry bulb temperature control accuracy: ±0.1℃
5. Wet bulb temperature control accuracy: ±0.1℃
6. Repeatability accuracy: ±1%
7. Accuracy: ±2%
8. Indoor and outdoor thermal balance ratio: ±2%
