400-816-6687RXCBE-5800 Capacitor Ripple Current Test Device
一、Overview:
The capacitor ripple current test device is a special device for capacitor current withstand temperature rise test. During the test, an AC voltage can be superimposed on the DC voltage to perform a high-frequency ripple durability test on the capacitor. It has the characteristics of high DC output voltage, large AC output current, high stability and easy operation; it supports data storage and recording, uses ARM to generate PWM waveforms and control, and users only need to automatically apply test conditions according to test requirements. At the same time, it uses DDS digital frequency synthesis technology to achieve high frequency and high current output, and has overvoltage and overcurrent protection functions.
二、Scope of application:
2.1、DC-link capacitor thermal stability test
2.2、 High frequency ripple durability test of film capacitors
2.3、Aluminum electrolysis ripple test
2.4、Safety capacitor temperature rise test
2.5、 Ceramic capacitor ripple current withstand test
2.6、High frequency ripple durability test of tantalum capacitors
2.7、Other capacitor ripple tests, transformer parameter performance tests, battery ripple tests and other magnetic material tests
三、Technical features：
3.1、 Use 7-inch/10-inch true color touch screen for system parameter display and control.
3.2、 Data power-off preservation.
3.3、 With wide frequency, you can choose freely in the frequency range of 45Hz~500kHz.
3.4、 It has a large current and can support up to 1000A.
3.5、 AC voltage up to 1500V.
3.6、 The maximum DC bias voltage supported is 5000V.
3.7、 Optional temperature detection module, using high-precision K-type thermocouple, small size, easy to install.
3.8、 Real-time monitoring of ripple current and voltage, with historical data storage.
3.9、 Supports historical data curve waveform drawing and USB disk data copy.
3.10、 When the test is finished or an abnormal situation occurs, the test is stopped and an alarm is given, and the sample is discharged.
3.11、 With automatic protection such as over-temperature, over-current, over-voltage, IGBT failure, etc.
3.12、 Optional test management software for easy data analysis and management.
RXCBE-5800 Capacitor Ripple Current Test Device
一、Overview:
The capacitor ripple current test device is a special device for capacitor current withstand temperature rise test. During the test, an AC voltage can be superimposed on the DC voltage to perform a high-frequency ripple durability test on the capacitor. It has the characteristics of high DC output voltage, large AC output current, high stability and easy operation; it supports data storage and recording, uses ARM to generate PWM waveforms and control, and users only need to automatically apply test conditions according to test requirements. At the same time, it uses DDS digital frequency synthesis technology to achieve high frequency and high current output, and has overvoltage and overcurrent protection functions.
二、Scope of application:
2.1、DC-link capacitor thermal stability test
2.2、 High frequency ripple durability test of film capacitors
2.3、Aluminum electrolysis ripple test
2.4、Safety capacitor temperature rise test
2.5、 Ceramic capacitor ripple current withstand test
2.6、High frequency ripple durability test of tantalum capacitors
2.7、Other capacitor ripple tests, transformer parameter performance tests, battery ripple tests and other magnetic material tests
三、Technical features：
3.1、 Use 7-inch/10-inch true color touch screen for system parameter display and control.
3.2、 Data power-off preservation.
3.3、 With wide frequency, you can choose freely in the frequency range of 45Hz~500kHz.
3.4、 It has a large current and can support up to 1000A.
3.5、 AC voltage up to 1500V.
3.6、 The maximum DC bias voltage supported is 5000V.
3.7、 Optional temperature detection module, using high-precision K-type thermocouple, small size, easy to install.
3.8、 Real-time monitoring of ripple current and voltage, with historical data storage.
3.9、 Supports historical data curve waveform drawing and USB disk data copy.
3.10、 When the test is finished or an abnormal situation occurs, the test is stopped and an alarm is given, and the sample is discharged.
3.11、 With automatic protection such as over-temperature, over-current, over-voltage, IGBT failure, etc.
3.12、 Optional test management software for easy data analysis and management.
