It is suitable for the early research and development, later type test, reliability test, and production line product delivery test of electric vehicle motors and their controllers, electric vehicle powertrain systems, etc. It meets the power supply requirements of the test items in GB/T18488.1-2015, GB/T18488.2-2015, and GB/T29307-2012.
Product Features
1. It has three output modes: constant voltage and constant current, DC programming, and battery simulation.
2.
It has built-in 5 battery simulation characteristic curves, including
lithium iron phosphate, ternary lithium, lithium manganese oxide, and
lithium cobalt oxide, and the user can customize 5 battery
characteristic curves.
3. It adopts four-quadrant control
technology, and the energy flows in both directions within the full
power, which is stable and reliable, energy-saving and efficient.
4. It has multiple output modes of constant voltage, constant current, and constant power.
5. The transient response is fast, ≤5ms.
6. It adopts high-speed digital control technology, and the output accuracy reaches 0.1%.
7.
It adopts PWM rectification technology, the power factor is >0.99,
the input harmonic is <3%, and the efficiency is greater than 93%.
8. It has automatic voltage drop compensation function, which automatically compensates for the line voltage drop.
9. It adopts a seven-inch touch screen operation, which is convenient to operate and display.
10.
The output parameters and protection parameters are programmable, which
can be applied to different types of equipment testing.
11. The internal components are from international brands such as LEM and Infineon, and the equipment is highly reliable.
12. The modular design makes the equipment easy to maintain.
It is suitable for the early research and development, later type test, reliability test, and production line product delivery test of electric vehicle motors and their controllers, electric vehicle powertrain systems, etc. It meets the power supply requirements of the test items in GB/T18488.1-2015, GB/T18488.2-2015, and GB/T29307-2012.
Product Features
1. It has three output modes: constant voltage and constant current, DC programming, and battery simulation.
2. It has built-in 5 battery simulation characteristic curves, including lithium iron phosphate, ternary lithium, lithium manganese oxide, and lithium cobalt oxide, and the user can customize 5 battery characteristic curves.
3. It adopts four-quadrant control technology, and the energy flows in both directions within the full power, which is stable and reliable, energy-saving and efficient.
4. It has multiple output modes of constant voltage, constant current, and constant power.
5. The transient response is fast, ≤5ms.
6. It adopts high-speed digital control technology, and the output accuracy reaches 0.1%.
7. It adopts PWM rectification technology, the power factor is >0.99, the input harmonic is <3%, and the efficiency is greater than 93%.
8. It has automatic voltage drop compensation function, which automatically compensates for the line voltage drop.
9. It adopts a seven-inch touch screen operation, which is convenient to operate and display.
10. The output parameters and protection parameters are programmable, which can be applied to different types of equipment testing.
11. The internal components are from international brands such as LEM and Infineon, and the equipment is highly reliable.
12. The modular design makes the equipment easy to maintain.
