400-816-6687RX9527 single-phase universal motor load cabinet
1. Overview:
This
life test load cabinet is designed in accordance with the requirements
for resistance, inductance, and motor load in standards such as IEC
60947-1:2014, GB2099, GB7261, GB14048, GB14598.1, GB15092, and GB16915.
2. Technical parameters
2.1. Control power supply: single-phase AC220V 1KVA
2.1.1. Test power supply: single-phase AC5~300V 50/60Hz at least 35KVA
2.2. Load output station: 1 station
2.3. Test voltage: single-phase AC5~280V
2.4. Load mode:
①. Resistive load: Current: AC0.5~100A continuously adjustable,
Resistance
is continuously adjustable from 0.1~600Ω, with a minimum adjustment
resolution of 0.01Ω, and a current step value of 0.1A or 1% of the rated
value
Except for large-value resistors, constantan wire is used
for winding, and the change rate of the resistor after heating is small,
the current parameters are stable, and it is reliable for long-term use
②. Inductive load: Current: AC0.5~100A continuously adjustable
Power factor: 0.3~1 Continuously adjustable;
Inductance
is continuously adjustable from 1 to 2048mH, with a minimum adjustment
resolution of 0.03mH (0.03mH impedance is approximately 0.01Ω)
RX9527 single-phase universal motor load cabinet
1. Overview:
This life test load cabinet is designed in accordance with the requirements for resistance, inductance, and motor load in standards such as IEC 60947-1:2014, GB2099, GB7261, GB14048, GB14598.1, GB15092, and GB16915.
2. Technical parameters
2.1. Control power supply: single-phase AC220V 1KVA
2.1.1. Test power supply: single-phase AC5~300V 50/60Hz at least 35KVA
2.2. Load output station: 1 station
2.3. Test voltage: single-phase AC5~280V
2.4. Load mode:
①. Resistive load: Current: AC0.5~100A continuously adjustable,
Resistance is continuously adjustable from 0.1~600Ω, with a minimum adjustment resolution of 0.01Ω, and a current step value of 0.1A or 1% of the rated value
Except for large-value resistors, constantan wire is used for winding, and the change rate of the resistor after heating is small, the current parameters are stable, and it is reliable for long-term use
②. Inductive load: Current: AC0.5~100A continuously adjustable
Power factor: 0.3~1 Continuously adjustable;
Inductance is continuously adjustable from 1 to 2048mH, with a minimum adjustment resolution of 0.03mH (0.03mH impedance is approximately 0.01Ω)
