RX9790 Refrigerator Compressor Continuous Overload Test Device
一、Overview
1. Technical parameters
1. Test range: 50~300W single phase (50/60Hz)
2.
Output single phase voltage according to the set test voltage. The
compressor frequency (50/60Hz) and test voltage are adjustable during
the test; the voltage sampling position is at the compressor terminal.
3. Test items: compressor continuous overload test, final disconnection test
4. Working fluid: R22, R134a, etc.
5. Workstation: single station
6. Working condition control range:
Intake pressure: 0.1~1.5Mpa, manually adjusted needle valve control
Return air temperature: 15~50, control accuracy ±1℃, automatic adjustment
Exhaust pressure: 0.1~5Mpa, control accuracy ±0.02Mpa, automatic adjustment
Evaporation temperature, condensation temperature: calculated from the suction and exhaust pressure test points
Test environment temperature: ring +10~50, control accuracy ±1℃, automatic adjustment
7.
Test parameters: compressor voltage/current, suction/exhaust pressure,
evaporation temperature, condensation temperature, return air
temperature, main and auxiliary coil resistance, winding coil
temperature, shell and cover temperature, PTC shell, ambient temperature
and other parameters, of which the number of temperature measurement
points is 8
RX9790 Refrigerator Compressor Continuous Overload Test Device
一、Overview
1. Technical parameters
1. Test range: 50~300W single phase (50/60Hz)
2. Output single phase voltage according to the set test voltage. The compressor frequency (50/60Hz) and test voltage are adjustable during the test; the voltage sampling position is at the compressor terminal.
3. Test items: compressor continuous overload test, final disconnection test
4. Working fluid: R22, R134a, etc.
5. Workstation: single station
6. Working condition control range:
Intake pressure: 0.1~1.5Mpa, manually adjusted needle valve control
Return air temperature: 15~50, control accuracy ±1℃, automatic adjustment
Exhaust pressure: 0.1~5Mpa, control accuracy ±0.02Mpa, automatic adjustment
Evaporation temperature, condensation temperature: calculated from the suction and exhaust pressure test points
Test environment temperature: ring +10~50, control accuracy ±1℃, automatic adjustment
7. Test parameters: compressor voltage/current, suction/exhaust pressure, evaporation temperature, condensation temperature, return air temperature, main and auxiliary coil resistance, winding coil temperature, shell and cover temperature, PTC shell, ambient temperature and other parameters, of which the number of temperature measurement points is 8
