400-816-6687Model: Multi-channel power analyzer 8962A1
Input unit: six-channel
Basic accuracy: 0.15 level (±0.1% of reading + 0.05% of range)
Measurement bandwidth: DC & 0.5Hz-300KHz
Input range: voltage: 1000V; current: 50A.
Measurement parameters: voltage U, current I, frequency f, active power P, reactive power Q, apparent power S,
Power factor PF, peak voltage U±PK, peak current I±PK, peak factor CF, electric energy accumulation E,
Harmonic distortion, harmonic components, efficiency, etc.
Allowable overload: 120% of the voltage and current range.
Sampling rate: 200K times/second (16-bit voltage and current sampling at the same time).
Line filtering: Analog filter: cut-off frequency is 500Hz
Digital filter: cut-off frequency is 1KHz~100kHz.
(100Hz step within 10KHz, continuously adjustable; 1KHz step above 10KHz, continuously adjustable.)
Frequency filter: cut-off frequency is 500Hz.
Efficiency measurement: can test input and output efficiency.
Speed torque: optional: speed torque interface.
Display mode: 8-inch color LCD screen 800*600 dots (H*V).
Communication interface: standard: UBS, RS232, RS485 and Ethernet port.
Instrument weight: about 12Kg
Power consumption of the whole machine: <25VA
Working power supply: AC 85V~265V, 50/60Hz.
Model: Multi-channel power analyzer 8962A1
Input unit: six-channel
Basic accuracy: 0.15 level (±0.1% of reading + 0.05% of range)
Measurement bandwidth: DC & 0.5Hz-300KHz
Input range: voltage: 1000V; current: 50A.
Measurement parameters: voltage U, current I, frequency f, active power P, reactive power Q, apparent power S,
Power factor PF, peak voltage U±PK, peak current I±PK, peak factor CF, electric energy accumulation E,
Harmonic distortion, harmonic components, efficiency, etc.
Allowable overload: 120% of the voltage and current range.
Sampling rate: 200K times/second (16-bit voltage and current sampling at the same time).
Line filtering: Analog filter: cut-off frequency is 500Hz
Digital filter: cut-off frequency is 1KHz~100kHz.
(100Hz step within 10KHz, continuously adjustable; 1KHz step above 10KHz, continuously adjustable.)
Frequency filter: cut-off frequency is 500Hz.
Efficiency measurement: can test input and output efficiency.
Speed torque: optional: speed torque interface.
Display mode: 8-inch color LCD screen 800*600 dots (H*V).
Communication interface: standard: UBS, RS232, RS485 and Ethernet port.
Instrument weight: about 12Kg
Power consumption of the whole machine: <25VA
Working power supply: AC 85V~265V, 50/60Hz.
