The MP series programmable DC test power supply (hereinafter referred
to as MP series power supply) is a high-power test power supply with
exquisite appearance and excellent performance. It adopts the
international standard 3U chassis, provides a power output capacity of
up to 15KW, has a variety of excellent performances, and has
unprecedented flexibility.
The MP series power supply has
automatic range and wide range output capability. Reducing the output
current can obtain a higher voltage or reducing the output voltage can
obtain a larger output current, providing more comprehensive power
supply test capabilities.
1. Automatic range, wide range output
2. Three-phase input 340~460VAC, power factor exceeds 0.99
3. Efficiency up to 95.5%
4. Output power range: 0~5KW, 0~10KW, 0~15KW, and can be expanded to 150KW
5. Output voltage: 0~80V to 0~1500V
6. Output current: 0~20A to 0~510A, and can be expanded to 3060A
7.
Complete protection functions: software/hardware overvoltage,
overheating, overcurrent, overpower, module failure, output overcurrent,
etc.
8. The three working modes of constant voltage, constant
current, and constant power are automatically switched to meet more test
needs
9. Arbitrary waveform generator with multiple waveform
editing modes, built-in multiple independent curves, supports
multi-curve loop and link, and provides users with fast and accurate
test waveforms
10. Powerful function settings such as adjustable
range configuration, alarm configuration, knob function configuration,
communication configuration, software protection configuration, system
information configuration, automatic backlight adjustment configuration,
etc.
11. Support multiple remote controls, standard RS485,
optional RS232/ETHERNET/USB/CAN communication control, optional analog
control
12. Support built-in discharge module, maximum discharge power can reach 5KW
The MP series programmable DC test power supply (hereinafter referred to as MP series power supply) is a high-power test power supply with exquisite appearance and excellent performance. It adopts the international standard 3U chassis, provides a power output capacity of up to 15KW, has a variety of excellent performances, and has unprecedented flexibility.
The MP series power supply has automatic range and wide range output capability. Reducing the output current can obtain a higher voltage or reducing the output voltage can obtain a larger output current, providing more comprehensive power supply test capabilities.
1. Automatic range, wide range output
2. Three-phase input 340~460VAC, power factor exceeds 0.99
3. Efficiency up to 95.5%
4. Output power range: 0~5KW, 0~10KW, 0~15KW, and can be expanded to 150KW
5. Output voltage: 0~80V to 0~1500V
6. Output current: 0~20A to 0~510A, and can be expanded to 3060A
7. Complete protection functions: software/hardware overvoltage, overheating, overcurrent, overpower, module failure, output overcurrent, etc.
8. The three working modes of constant voltage, constant current, and constant power are automatically switched to meet more test needs
9. Arbitrary waveform generator with multiple waveform editing modes, built-in multiple independent curves, supports multi-curve loop and link, and provides users with fast and accurate test waveforms
10. Powerful function settings such as adjustable range configuration, alarm configuration, knob function configuration, communication configuration, software protection configuration, system information configuration, automatic backlight adjustment configuration, etc.
11. Support multiple remote controls, standard RS485, optional RS232/ETHERNET/USB/CAN communication control, optional analog control
12. Support built-in discharge module, maximum discharge power can reach 5KW
Zhipinhui After-Sales Policy:
*After-Sales Hotline: +864008166687
1. Our company has assembled a team of experienced field engineers and senior technicians to promptly respond
to any equipment issues and provide after-sales maintenance.
2. Within China, within one week of new product delivery, our after-sales technical staff will install the equipment and
provide after-sales training at the customer's location, using the contact information and address provided by the customer.
3. All complaints related to product quality will be responded to within one hour. Within 3-5 hours within the province,
and within 24-48 hours outside the province, we will arrive at the customer's site,
determine the appropriate action based on the complaint, and provide after-sales repairs. (Domestic)
4. For international travel, our company can also arrange for an after-sales engineer to visit you for installation and
commissioning. Please discuss any travel and catering issues in advance.
We also provide video installation guides for you to choose from, providing you with a comprehensive and multi-faceted solution.
5. Any material costs related to product quality during the warranty period will be borne by our company.
6. During the warranty period, we will provide free repairs due to improper use or environmental factors.
The materials and accessories used for repairs will be charged at cost only.
