400-816-6687ZH9902 Electronic Expansion Valve Comprehensive Performance Test Bench (Household Air Conditioning Expansion Valve)
一、Brief Introduction of Electronic Expansion Valve Comprehensive Performance Test Bench
This machine is designed according to JBT-10212 and JBT-10386, and is
suitable for testing electronic expansion valves of household or
commercial air conditioners, including flow characteristics, valve
opening pulse, valve port leakage, and maximum operating pressure
difference tests.
二、Technical parameters
2.1、Test object: Electronic expansion valve (domestic or commercial air conditioner)
2.2、Power supply: AC220V, 50HZ. Power, about 1KW;
2.3、Gas source: clean high-purity nitrogen above 6Mpa;
2.4、Operating environment:
① Humidity range 38∽85% RH (non-condensing environment)
② Temperature range Room temperature ~ 40℃
③ No strong electric field or strong magnetic field interference
④ Stable gas source pressure
2.5、Number of test stations: 1
2.6、Test items:
① Valve leakage test
② Flow characteristics test
③ Maximum valve opening pressure difference test
④ Valve opening pulse test
ZH9902 Electronic Expansion Valve Comprehensive Performance Test Bench (Household Air Conditioning Expansion Valve)
This machine is designed according to JBT-10212 and JBT-10386, and is suitable for testing electronic expansion valves of household or commercial air conditioners, including flow characteristics, valve opening pulse, valve port leakage, and maximum operating pressure difference tests.
二、Technical parameters
2.1、Test object: Electronic expansion valve (domestic or commercial air conditioner)
2.2、Power supply: AC220V, 50HZ. Power, about 1KW;
2.3、Gas source: clean high-purity nitrogen above 6Mpa;
2.4、Operating environment:
① Humidity range 38∽85% RH (non-condensing environment)
② Temperature range Room temperature ~ 40℃
③ No strong electric field or strong magnetic field interference
④ Stable gas source pressure
2.5、Number of test stations: 1
2.6、Test items:
① Valve leakage test
② Flow characteristics test
③ Maximum valve opening pressure difference test
④ Valve opening pulse test
