ZH-9902 Automobile Electronic Expansion Valve Comprehensive Test Equipment

一、Introduction to the comprehensive performance test bench for automotive electronic expansion valves

This machine is customized according to customer requirements and is suitable for testing the valve port leakage, valve opening pulse, maximum operating pressure difference (OMPD),
and flow characteristics of automotive electronic expansion valves.Using mass flow meter, the flow test accuracy is ±1%.
The system is automatically controlled, the output test pressure is adjusted by a proportional valve, and the number of expansion valve input pulses can be set.
After setting the parameters on the computer, start the test with one click, generate the flow characteristics, valve port leakage parameter curve and record the test results;

二、Technical indicators
2.1、Test object: automotive electronic expansion valve
2.2、Test station: 1

2.3、test items：① Valve port leakage test
                             ② Valve opening pulse test
                             ③ Forward maximum valve opening pressure difference test
     ④ Flow characteristic test
2.4、Power supply: AC220V, 50HZ. Power, about 1KW;

2.5、Gas source: clean high-purity nitrogen or compressed air above 6Mpa
2.6、The test items can be checked in the program, which is convenient and flexible
2.7、Flow characteristic test range: 0~250l/min

ZH-9902 Automobile Electronic Expansion Valve Comprehensive Test Equipment

一、Introduction to the comprehensive performance test bench for automotive electronic expansion valves

This machine is customized according to customer requirements and is suitable for testing the valve port leakage, valve opening pulse, maximum operating pressure difference (OMPD),
and flow characteristics of automotive electronic expansion valves.Using mass flow meter, the flow test accuracy is ±1%.
The system is automatically controlled, the output test pressure is adjusted by a proportional valve, and the number of expansion valve input pulses can be set.
After setting the parameters on the computer, start the test with one click, generate the flow characteristics, valve port leakage parameter curve and record the test results;

二、Technical indicators
2.1、Test object: automotive electronic expansion valve
2.2、Test station: 1
